EE-1000
EE-1000 Series
Intel Celeron N5105
Fanless | Made by SNUC
Form
- Intel Celeron N5105
- Intel UHD Graphics
- Soldered LPDDR4 32GB Max Up to 2933MHz
- 256GB Primary storage (up to 2TB)
- 1x HDMI
- 2x USB-A 3.2
- 1x mDP
- 2x 2.5GbE
- 1x BMC
- 12V DC 48W Power Supply
Features
The first of its kind, NANO-BMC out-of-band management in a small form factor enables remote management of edge devices at the extremeEDGE. Remote access to hardware even when powered off (useful for troubleshooting). Increased uptime, faster problem resolution and reduced support costs. Improved power management and resource utilisation.
Made by SNUC.
Processor
Intel® Celeron® Processor N5105 4M Cache, up to 2.90 GHz
Turbo boost
2.90 GHz
Cores / threads
4 Cores / 4 Threads
Operating temp.
Ambient Operating Temp
Graphics
Max Resolution 3840 x 2160 | Intel UHD Graphics
Memory
Soldered LPDDR4 | 32GB Max | Up to 2933MHz
Storage
256GB Primary storage (up to 2TB)
Networking
2x 2.5GbE, 1x BMC
Inputs
1x USB-C, 2x USB-A 3.2, 3x USB-C 2.0
Power supply
12V DC 30W Power Supply
Configuration
Customise your NUC with the options below and they will all come pre-installed.
